Smart Panel Light Driver

Tunable White, App-Controlled

Smart CCT COB Light Driver

Tunable White, App-Controlled

The Beakn Smart Panel Light Driver is a WiFi-enabled LED driver that makes any standard LED panel light — round, square, surface-mounted, or recessed — app-controlled, voice-controlled, and tunable from warm to cool white.

Buy Now Talk to a Beakn Expert

36W

Support upto

CCT

2500K -6500K

0 to 100%

Dimming

4kV

Surge Protection

Same ceiling. Same lights. Same wiring.

Now warm at dinner. Cool while working. Dim when sleeping.
It replaces the standard non-smart driver inside the panel housing without changing the panel itself, the wiring, or the false ceiling. Two variants cover panel wattages from 12W to 36W. The driver tunes light from 2500K (warm) to 6500K (cool), dims from 0% to 100%, and works with the Beakn app, Apple Siri, Google Assistant, and Amazon Alexa. Wide input range 90VAC–300VAC handles Indian voltage fluctuations. Prices start at ₹624 including GST with a 3-year warranty.

View All Panel light Drivers
The Problem it solves

One Panel. Every Mood. No Renovation.

The Beakn Smart Panel Light Driver fixes this without renovating your ceiling. Replace the dumb driver behind the panel with the Beakn driver. Now the same panel goes from 2500K (warm yellow) to 6500K (cool daylight) and dims from 0% to 100% — all from your phone, all over WiFi, with no hub.

HARDWARE features

What This Driver Does

Tune the same panel light from 2500K (warm yellow, like halogen) to 6500K (cool white, like daylight). Pick any temperature in between — 4000K neutral white for work, 3000K warm for dinner, or any custom value. Set it manually in the app, or schedule it to shift automatically through the day. Tunable white control requires a CCT-capable panel (one with separate warm and cool LED chips). Most modern Indian panels are CCT-capable; check your panel spec before buying.

Dim the panel from 0% to 100% using high-frequency PWM (Pulse Width Modulation) — flicker-free across the full range. Cheap drivers flicker noticeably below 30%, which causes eye strain over long work hours. The Beakn driver maintains stable, flicker-free output even at 5% brightness, which matters for late-night reading, child bedrooms, and anyone sensitive to flicker.

Accepts input from 90V to 300V AC at 50Hz or 60Hz. Indian apartment grid voltage typically swings between 180V and 260V; transformer switching and grid restoration after outages can spike above 280V. The driver runs stably across that full range. No external stabiliser is needed for the driver itself.

Built-in surge protection rated up to 4.5kV protects the driver and the connected panel from voltage spikes caused by lightning, grid switching, and power restoration. Particularly important for panels installed in upper-floor apartments and standalone houses where grid surges are more frequent. [NEEDS VERIFICATION: confirm against test report]

Short-circuit protection: if the panel output is short-circuited (e.g. damaged cable), the driver shuts down immediately and recovers automatically when power is reset. Over-voltage protection: same auto-recovery behaviour if input voltage exceeds the safe range. No fuses to replace, no manual reset, no electrician callback for nuisance trips.

HARDWARE efficiency

What This Driver Does

Uses an isolated flyback power supply design. Input (mains) and output (LED) circuits are electrically separated by a transformer. Practical benefit: reduced electrical noise on the panel output, better LED life, and improved safety if any output wire is accidentally exposed. Many sub-₹500 drivers use cheaper non-isolated topologies that compromise on noise and safety.

Total Harmonic Distortion stays at or below 10% at full load on 230VAC. Lower THD means less interference fed back into your home wiring (which can affect other appliances) and cleaner panel output. Critical for home offices, study rooms, and any space where people spend long hours under the panel.

Typical efficiency of 90% at 230VAC input. For a 36W panel load, that means roughly 40W input from the mains — only 4W lost as heat in the driver. Higher efficiency means less heat trapped in your false ceiling cavity and longer driver life. Important when 4–8 panels share the same enclosed ceiling space. [NEEDS VERIFICATION: confirm against test report]

Rated for –10°C to +65°C ambient operation, with 20–95% RH humidity tolerance. False-ceiling cavities in Indian apartments routinely hit 45–55°C in summer afternoons. The driver is rated to handle that, plus the humidity of monsoon and coastal cities like Mumbai, Chennai, and Vizag.

Works with Apple Siri (and Siri Shortcuts, Apple Watch, CarPlay, Focus Modes), Google Assistant, and Amazon Alexa. Say “Hey Siri, set living room panel to warm white at 50%,” “Alexa, turn the home office panel to 5500K,” or “Hey Google, dim bedroom panel to 20%.” Voice commands work in standard English.

Variants and Pricing

Pick the Right Variant for Your Panel



Which Variant Should You Pick?

Match the driver wattage to your panel’s actual wattage. The driver wattage range must include your panel’s wattage — never run a panel above the driver’s rated maximum.Each panel needs its own Smart Panel Light Driver — one driver controls one panel. The benefit: each panel can be controlled independently in the app, and a failure in one driver does not affect the others. The Beakn app lets you group multiple panels into a Room or a Scene, so you can control all of them with one tap or one voice command, even though they are technically separate devices.



What You Can Do With Tunable Lighting

Home office panel at 5000K cool-neutral, 100% during work hours; auto-shifts to 3000K warm at 50% after 6:30 PM

One tap → dining + living room panels drop to 2700K warm at 50% brightness for evening meals

Study panel at 5500K cool-neutral, scheduled 4:00 PM – 9:00 PM during school days; warms automatically after

Bedroom panel auto-warms to 2500K and dims to 10% at scheduled bedtime; full off when motion stops

20 App Features — Standard on Every Beakn Device

All features are free. No subscription. No premium tier.

The Smart Panel Light Driver is controlled by the Beakn app — the same app that controls every Beakn switch, plug, sensor, and motor in your home. All 20 app features apply: schedules, scenes, routines, sunrise/sunset automation, voice assistants, NFC tags, Apple Siri Shortcuts, running-hours tracking, ON/OFF history, energy estimates, offline mode (your schedules keep running even when internet is down), and Safe Mode voltage protection. No subscription. No premium tier. No hidden monthly costs.

See all features in detail

Technical Specifications

Power Input

240V AC, 50/60Hz

Colour Temperature Range

2500K – 6500K

Dimming Range

0% – 100%

Dimming Method

PWM

Flicker Level

Flicker Free

Total Harmonic Distortion (THD)

≤ 10% @ full load, 230VAC

Short Circuit Protection

Yes

Power Efficiency

90%

Output Current

Up to 750mA

Standby Power

Less than 0.8W

Power Supply Topology

Isolated Flyback

Surge Protection

up to 4KV

Connectivity

WiFi (2.4GHz) — direct to cloud, no hub

Voice Assistants

Google Assistant, Alexa, Apple Siri, Apple HomeKit

Offline Control

Yes

Warranty

3 years

Why Beakn — The Engineering Behind the Driver

The Smart Panel Light Driver is manufactured by a manufacturer with 10+ years of experience in smart home and lighting electronics in India. Drivers are tested in NABL-accredited laboratories against the mandatory BIS standard for LED drivers. Anti-surge testing is performed up to 4.5kV. The Beakn mobile app and cloud platform are 100% in-house developed in India — not based on Tuya, eWeLink, or any third-party platform. Every driver carries a 3-year warranty against electrical or firmware defects.

Certifications Warranty

FAQ

Frequently Asked Questions — Smart Panel Light Driver

It works with any LED panel light whose wattage falls between 12W and 36W (using either the 12W–24W or 24W–36W variant), and whose output specs match the driver’s range — typically 32V–48V DC output with appropriate current rating. For tunable white control, the panel itself must be CCT-capable (separate warm and cool LED chips). For brightness-only control, single-CCT panels also work. Send a photo of your panel’s driver label to Beakn on WhatsApp to confirm before ordering.

Yes. Every LED panel light has a separate driver — usually a small box wired to the panel and mounted on top of the housing or above the false ceiling. Replace that standard non-smart driver with the Beakn Smart Panel Light Driver and the same panel becomes app-controlled, voice-controlled, and tunable from warm to cool white. The panel, the LED, the housing, and all wiring stay exactly as they are. An electrician makes the swap in under 15 minutes per panel.

The Beakn Smart Panel Light Driver covers panel wattages from 12W to 36W across two variants — the 12W–24W variant for standard panels (round 12W/15W/18W, square 18W/24W) and the 24W–36W variant for higher-wattage panels (24W/30W/36W). Match the driver wattage to your panel’s actual wattage; never run a panel above the driver’s rated maximum.

No. The driver connects directly to your home WiFi (2.4GHz) and the Beakn cloud. There is no hub, bridge, gateway, or coordinator. Each driver is independently connected — if one fails or loses power, the others keep working. App control, voice control, and scheduling all run without any additional hardware.

Yes. The driver uses high-frequency PWM (Pulse Width Modulation) and is rated flicker-free across the full 0–100% range, including very low brightness levels. Cheap drivers flicker noticeably below 30%, which causes eye strain over long work-from-home sessions. The Beakn driver maintains stable output even at 5% brightness — important for night-mode and child bedrooms.

The driver works with Apple Siri (including Siri Shortcuts, Apple Watch, CarPlay, and Focus Modes), Google Assistant, and Amazon Alexa via the Beakn app integration. You can set a routine like “set workspace panels to 5500K and 100%” with one voice command. Apple HomeKit native support: confirm current status with Beakn support before purchase.
